BATTEN Fences- 40x40mm - Custom Cut - SQM Guide - White and other Colours
- Availability: In Stock
- Product Code: Aluminium Screening
- $179.00
Modern Contemporary Batten Fencing & Facades
Custom-cut to any size • Premium Aluminium • DIY System
THIS IS A DIY PRODUCT — EASY TO FIT & INSTALL
Using our exclusive DIY Batten System.
How to Get Fast Prices
- SMS your sizes to 0414 237 573
- Tell me the height & width of each panel between your posts
- Max width between posts is approx 3000mm
- If you want a seamless front with posts behind, max panel is 5000mm
- Tell me your batten colour
- Choose gaps: 40mm, 80mm or 120mm
Example: A 2200w × 1400h screen with 80mm gaps, built Vertical in Black / White / Dark Grey ≈ $554 (≈ $179 per sqm). Cut-to-size and supplied as a flat-packed DIY kit.
Our Precision Rail System
The multi-purpose top & bottom rails have pre-punched holes every 40mm for a perfect vertical system in any height or width. Screws sit inside the channel, and our aluminum cover trims conceal all fixings for a clean, architectural finish.
We can supply rails without using the pre-punched holes. You can freestyle any gap size you want — just note it will require a little extra care during assembly.
Understanding Batten Spacing
- Rails set at 80mm centres = 40mm gaps
- Rails set at 120mm centres = 80mm gaps
- Rails set at 160mm centres = 120mm gaps
Battens are 40×40mm. They protrude 40mm forward from the horizontal rail. Internal ribs + screw-connection = as strong as welding.
Available Colours
- Satin Black
- Dark Grey (Monument-like)
- Gloss White
Connection Options
Standard quoting uses brackets fixing to the side of your posts (panels sit between posts). For a seamless front look, request Saddle Brackets which mount to the front of your posts. Max length for saddle-mounted panels: 5000mm.
You can build between brick piers, timber, steel or our aluminium posts:
- 76×76mm Aluminium Posts — $40/m
- 100×100mm Aluminium Posts — $70/m
DIY System – Premium Features
- Strongest battens in Australia — 2 internal ribs
- Top-quality powder coated aluminium — no rust
- Fully concealed fixings
- Black/White plastic batten caps included
- Rail hole plugs included (optional)
Simple Install Steps
- Fix top & bottom rails to your posts with brackets
- Measure 10% of batten height to set rail intersection
- Mark batten screw line with a marker
- Two people: screw first batten through rail hole into batten rib side
- Continue the top row, then fix the bottom rail
- Leave your selected gap between battens
We cut, you TEK it together at home.
What You Should Know
- $100 deposit per custom panel for pickups
- We cut Tuesdays & Thursdays
- Protective film left on material
- Allow 3–6mm tolerance in final sizes
- Gaps quoted (40 / 80 / 120) are between battens
- Battens cannot start/end within 30mm due to bracket zone
Direct From the Warehouse
10 Richards Rd, Narangba 4504
(Across the highway from Costco)
Delivery – Bulky Goods
- 1 panel/gate Australia-wide = $120
- North Brisbane = $140
- South Brisbane = $200
- Gold Coast, Ipswich, Sunshine Coast = $250
- Sydney or Rockhampton = $350
- Melbourne or Townsville = $450
We use backload trucks — deliveries may be after hours. For other regions, we can quote to your home or town.
